Rox 01

$46,700.00

*Guide Price



The Rox 01 is a large, rugged plug-in hybrid extended-range SUV launched by Jish Stone on August 22, 2023. Positioned as a luxury vehicle for outdoor-oriented families, it measures 5295 × 1980 × 1869 mm, with a wheelbase of 3,010 mm. It features a boxy, rugged design, with a front fascia that combines a large grille and Y-shaped headlight clusters. The vehicle comes with a two-tone roof and an optional external spare tire.

If you want to stay up-to-date with the latest automotive news, please subscribe. We offer comprehensive information on all kinds of cars, auto news, blogs, and more.

Category: Tags: ,









Exterior Design

The ROX 01 adopts a square hard-core SUV body design, equipped with stone-shaped integrated LED headlight sets and LED daytime running lights. It features horizontal segmented LED taillight assembly and a tailgate-mounted full-size spare tire. The vehicle is fitted with electric suction doors and an electric tailgate. Available exterior body colors include Polar White, Basalt Gray, Emerald Green, Desert Gold and Obsidian Black.
In terms of dimensions, the vehicle measures 5,050 mm in length, 1,980 mm in width, and 1,869 mm in height, with a wheelbase of 3,010 mm. The car is equipped with 21-inch alloy wheels as standard. Standard exterior configurations include automatic headlights, rain-sensing wipers and a panoramic glass roof with electric sunshade.

Interior Design

The ROX 01 features a 12.3-inch digital instrument cluster and a 15.7-inch central touchscreen. The interior adopts Nappa leather upholstery materials, with optional interior color schemes including Amber Orange, Jade White, Pearl Black and Amethyst Purple. Standard configurations include front, side and curtain airbags, front and rear parking sensors, a panoramic camera system, and adaptive cruise control.
Higher-spec versions are equipped with L2-level intelligent driver-assistance systems, active braking, lane keeping assist and blind spot monitoring. Additional practical configurations include multi-way power-adjustable seats with heating, ventilation and massage functions, three-zone automatic climate control and 256-color interior ambient lighting. The vehicle provides 6-seat and 7-seat layout options.

Powertrain

The ROX 01 is equipped with a 1.5T four-cylinder range extender and dual-motor full-time four-wheel drive system. The front motor delivers a maximum power of 150 kW and a peak torque of 340 Nm, while the rear motor outputs a maximum power of 200 kW and a peak torque of 400 Nm. The comprehensive maximum power reaches 350 kW with a comprehensive peak torque of 740 Nm, with an official top speed of 190 km/h.
Standard-range models are equipped with a 44.5 kWh ternary lithium battery pack, while long-range models adopt a 58.4 kWh ternary lithium battery pack. The WLTC pure electric cruising range is 215 km for standard-range versions and 252 km for long-range versions. The comprehensive cruising range reaches 1278 km and 1362 km respectively. It supports 7 kW AC charging and 5.7 kW external power output, with a 0-100 km/h acceleration time of 5.5 seconds.
2023 Polaris 01 All-Purpose 7-Seat Edition2023 Polaris 01 Premium 6-Seat Edition
Basic Information
Availability2023.082023.08
vehicle classMid-size SUVMid-size SUV
Length*Width*Height(mm)5050*1980*18695050*1980*1869
Type of energyadd-on program (Tw)add-on program (Tw)
WLTC pure electric range (km)235235
CLTC pure electric range (km)282282
Combined system power (kW)350350
Combined system torque (N-m)740740
motor1.5T / 152 hp / inline 4-cylinder1.5T / 152 hp / inline 4-cylinder
Maximum power (kW)112112
Number of gears11
transmissionFixed Ratio GearboxFixed Ratio Gearbox
Maximum speed (km/h)190190
0-100km/h acceleration(s)5.55.5
WLTC Combined Fuel Consumption (L/100km)7.957.95
Battery TypeTernary lithium batteryTernary lithium battery
Battery capacity (kWh)56.0156.01
Fast charging time (h)0.480.48
Fast charging capacity (%)0-800-80
Warranty PolicyFive years or 100,000 kilometersFive years or 100,000 kilometers
body of automobile
Length (mm)50505050
Width (mm)19801980
Height (mm)18691869
Wheelbase (mm)30103010
Front wheelbase(mm)16921692
Rear wheelbase(mm)17011701
Weight (kg)26602580
Fuel tank volume (L)7070
Number of doors (pcs)55
Number of seats (pcs)76
motor
Displacement (mL)14961496
Maximum horsepower (Ps)152152
Maximum power (kW)112112
cylinder (engine)Inline 4-cylinderInline 4-cylinder
Intake formturbochargedturbocharged
valve traindouble overhead camshaftdouble overhead camshaft
Lubrication methoddirect injectiondirect injection
Cylinder materialaluminumaluminum
fuel grade95#95#
environmental standardCountry 6Country 6
electric motor
Total motor power (kW)350350
Total motor torque (N-m)740740
Maximum power of front electric motor (kW)150150
Maximum torque of front motor (N-m)340340
Maximum power of rear electric motor (kW)200200
Maximum torque of rear motor (N-m)400400
Combined system power (kW)350350
Combined system torque (N-m)740740
WLTC pure electric range (km)235235
CLTC pure electric range (km)282282
Battery capacity (kWh)56.0156.01
Slow charging time (h)8.68.6
Fast charging time (h)0.480.48
Motor structurepermanent magnetismpermanent magnetism
Principle of motor operationsynchronizationsynchronization
Number of drive motorsDual MotorDual Motor
Motor Layoutfront and rearfront and rear
Battery TypeTernary lithium batteryTernary lithium battery
Battery Cell BrandsNingde TimesNingde Times
Battery cooling methodliquid coolingliquid cooling
fast charging functionbe in favor ofbe in favor of
Fast charging capacity (%)0-800-80
Battery Pack WarrantyEight years or 160,000 kilometersEight years or 160,000 kilometers
external discharge●●
Chassis/steering
Driving formfour-wheel drivefour-wheel drive
Front suspension typedouble wishbone independent suspensiondouble wishbone independent suspension
Rear suspension typeMulti-link independent suspensionMulti-link independent suspension
Adjustable suspension●●
Steering assist formelectric power assistelectric power assist
Wheels/Brakes
Front/Rear Brake TypeVentilated tray typeVentilated tray type
Parking brake typeelectronic parkingelectronic parking
Front Tire Specification265/50 R20265/50 R20
Rear Tire Specification265/50 R20265/50 R20
Wheel Materialaluminumaluminum
Spare tire specificationTire Repair ToolsTire Repair Tools
Active/passive safety features
ABS anti-lock●●
Brake force distribution (EBD/CBC etc.)●●
Brake Assist (BA/EBA/BAS etc.)●●
Traction control (ASR/TCS/TRC etc.)●●
Stability Control (ESC/ESP/DSC etc.)●●
Active braking/safety systems●●
merging aid●●
lane keeping assist system●●
lane departure warning●●
Road traffic signage recognition●●
Fatigue Driving Alertscharacter used in Taiwan as a substitute for a real name (like "X" in English)character used in Taiwan as a substitute for a real name (like "X" in English)
DOW Open Door Alert●●
front exhaust airbag:: Driver's airbag:: Driver's airbag
●Passenger airbag●Passenger airbag
●Side airbags●Side airbags
●Head airbags (air curtains)●Head airbags (air curtains)
Rear airbags●Head airbags (air curtains)●Head airbags (air curtains)
Tire Pressure Detection Device●Display●Display
Seat Belt Reminder●Principal Driver●Principal Driver
●Passenger●Passenger
ISOFIX child restraints●●
Forward Collision Warning●●
Rear Collision Warning●●
Anti-Rollover System●●
Auxiliary/Manipulation Configurations
parking radar●Forward●Forward
● Post● Post
Driver Assistance Video●360-degree panoramic image●360-degree panoramic image
Transparent chassis/540 degree imagecharacter used in Taiwan as a substitute for a real name (like "X" in English)character used in Taiwan as a substitute for a real name (like "X" in English)
cruise control●Adaptive cruise at all speeds●Adaptive cruise at all speeds
Driving Mode Switching:: Campaigns:: Campaigns
:: Economy:: Economy
:: Standard/comfort:: Standard/comfort
:: Snow:: Snow
● Off-road● Off-road
steep incline and slow descent●●
hill-holding aid●●
automatic parking●●
automatic parking●●
remote control●●
Assisted driving level●L2●L2
External/anti-theft configurations
skylights:: Segmented non-opening sunroof:: Segmented non-opening sunroof
roof rack●●
Electric Suction Door●●
Side footrests○Fixed○Fixed
Key Type●Remote key●Remote key
● Bluetooth key● Bluetooth key
Keyless entry●●
Keyless Start System●●
Remote start function●●
Central locking in the car●●
electronic immobilizer●●
Internal Configuration
Steering wheel material● Leather● Leather
Steering Wheel Adjustment● Manual● Manual
Adjustable up and downAdjustable up and down
Adjustable front and rearAdjustable front and rear
Steering wheel functions●Heating●Heating
:: Multifunctionality:: Multifunctionality
center armrest●Forward●Forward
● Post● Post
Sun visor vanity mirror●●
Liquid crystal instrument size12.3 in.12.3 in.
Built-in car recorder●●
Wireless charging function for cell phones● Front row● Front row
Intelligent Hardware
Assisted Driving Chips○2 NVIDIA Orin-X.○2 NVIDIA Orin-X.
:: Dual TDA4:: Dual TDA4
Number of cameras● 6● 6
○11○11
Number of ultrasonic radars:: 12:: 12
○14○14
Number of millimeter-wave radars● 5● 5
Number of LiDAR○3○3
seating
Seat Material● Leather● Leather
Main Driver's Seat Function:: Memory:: Memory
:: Ventilation:: Ventilation
:: Massage:: Massage
●Heating●Heating
Passenger seat function:: Ventilation:: Ventilation
:: Massage:: Massage
●Heating●Heating
Seat electric adjustment●Principal Driver●Principal Driver
●Passenger●Passenger
Integral adjustment of the main driver's seat●Before and after●Before and after
●Backrests●Backrests
●High/Low (4-way)●High/Low (4-way)
Partial adjustment of the main driver's seat●Leg rests●Leg rests
:: Waist (4-way):: Waist (4-way)
Passenger seat overall adjustment●Before and after●Before and after
●Backrests●Backrests
●High/Low (4-way)●High/Low (4-way)
Partial adjustment of the passenger seat:: Waist (4-way):: Waist (4-way)
Second row seat adjustment●Angle adjustable●Angle adjustable
● Seat movement● Seat movement
●Proportional lowering●Proportional lowering
●Lumbar adjustment●Leg rest adjustment
●Lumbar adjustment
●High and low adjustment
Second row of individual seats●●
Passenger seat rear adjustable buttons●●
Rear Cup Holder●●
Third row of seats●●
Seat Layout2002/2/32002/2/2
multimedia
Large color screen in the center console●●
satellite navigation system●●
Navigating the road information display●●
Map BrandingBaiduBaidu
Roadside assistance calls●●
Automotive Intelligence ChipQualcomm Snapdragon 8155Qualcomm Snapdragon 8155
Bluetooth/Car Phone●●
Cell phone connectivity/mapping●CarPlay support●CarPlay support
●Factory connectivity/mapping●Factory connectivity/mapping
Number of audio speakers1414
Center screen size●15.7 inches●15.7 inches
Voice assistant wake wordsHello, Stone.Hello, Stone.
4G/5G networks●5G●5G
Telematics●●
OTA upgrade●●
Car KTV●●
Rear LCD screen size●15.6 inches●15.6 inches
Interface Support●USB port●USB port
●Type-C port●Type-C port
Power Support●220V/230V power supply●220V/230V power supply
illumination
low beam (headlights)●LED●LED
high beam (headlights)●LED●LED
LED daytime running lights●●
Adaptive high and low beam●●
Adjustable headlights●●
Automatic headlights●●
Delayed headlight off●●
Interior ambient lighting●●
Glass/Mirror
power window●Forward●Forward
● Post● Post
One-touch window lifting● Full vehicle● Full vehicle
Anti Window Pinch Handle●●
rearview mirror●Motorized adjustment●Motorized adjustment
:: Electric folding:: Electric folding
●Automatic anti-glare●Automatic anti-glare
:: Memory:: Memory
●Heating●Heating
●Automatic folding for locking the car●Automatic folding for locking the car
●Automatic reversing down●Automatic reversing down
rearview mirror●Automatic anti-glare●Automatic anti-glare
●Streaming rearview mirror●Streaming rearview mirror
Glass Functions:: Multi-layer soundproofing:: Multi-layer soundproofing
● Rear side privacy● Rear side privacy
inductive wiper●●
Air conditioners/refrigerators
Air conditioning control method● Automatic control● Automatic control
Individual air-conditioning in the rear●●
rear air vent●●
Temperature zone control●●
PM2.5 filtration●●
Negative Ion Generator●●
