Exterior Design
The Tesla Model 3 adopts a compact sedan body design with a closed front grille and integrated LED headlight sets. It is equipped with LED daytime running lights and full LED taillight assembly. The vehicle is fitted with hidden door handles and an electric trunk lid. Available exterior body colors include Solid Black, Midnight Silver Metallic, Deep Blue Metallic, Pearl White Multi-Coat and Red Multi-Coat.
In terms of dimensions, the vehicle measures 4,720 mm in length, 1,933 mm in width, and 1,442 mm in height, with a wheelbase of 2,875 mm. The car is equipped with 18-inch alloy wheels as standard, with optional 19-inch alloy wheels. Standard exterior configurations include automatic headlights and aerodynamic exterior components.
Interior Design
The Tesla Model 3 cancels the traditional digital instrument cluster and is equipped with a 15.4-inch central touchscreen and an optional 8-inch rear touchscreen. The interior adopts vegan leather upholstery materials, with optional interior color schemes including all-black and black-white dual tone. Standard configurations include front, side and curtain airbags, front and rear parking sensors, a 360-degree panoramic camera system, and cruise control.
The vehicle is equipped with standard advanced driver-assistance systems, active braking, lane keeping assist and blind spot monitoring. Additional practical configurations include multi-way power-adjustable front seats with heating functions, dual-zone automatic climate control and interior ambient lighting. The vehicle adopts a 5-seat layout.
Powertrain
The Tesla Model 3 offers rear-wheel-drive, dual-motor all-wheel-drive and dual-motor all-wheel-drive performance versions, all matched with a single-speed electric transmission. The rear-wheel-drive version delivers a maximum power of 194 kW, with an official 0-100 km/h acceleration time of 5.8 seconds and a top speed of 201 km/h. The long-range all-wheel-drive version outputs a comprehensive maximum power of 317 kW, with an official 0-100 km/h acceleration time of 3.8 seconds and a top speed of 200 km/h. The performance version outputs a comprehensive maximum power of 340 kW, with an official 0-100 km/h acceleration time of 3.1 seconds and a top speed of 261 km/h.
The vehicle is equipped with lithium-ion battery packs. The CLTC pure electric cruising range includes 634 km, 753 km and 647 km versions. The vehicle supports DC fast charging and AC slow charging with a peak supercharging power of 250 kW. The vehicle adopts front MacPherson independent suspension and rear multi-link independent suspension.
| 2024 Model 3 High Performance All-Wheel Drive Edition | 2023 Model 3 Rear Wheel Drive Edition | 2023 Model 3 Long Range All-Wheel Drive Edition | |
|---|---|---|---|
| Basic Information | |||
| Availability | 2024.04 | 2023.09 | 2023.09 |
| vehicle class | Mid-size trim | Mid-size trim | Mid-size trim |
| Length*Width*Height(mm) | 4724*1848*1430 | 4720*1848*1442 | 4720*1848*1442 |
| Type of energy | all-electric | all-electric | all-electric |
| CLTC pure electric range (km) | 623 | 606 | 713 |
| Total motor power (kW) | 343 | 194 | 331 |
| Total motor torque (N-m) | 723 | 340 | 559 |
| Maximum speed (km/h) | 261 | 200 | 200 |
| 0-100km/h acceleration(s) | 3.1 | 6.1 | 4.4 |
| Battery Type | Ternary lithium battery | lithium iron phosphate battery | Ternary lithium battery |
| Battery capacity (kWh) | 78.4 | 60 | 78.4 |
| Warranty Policy | Four years or 80,000 kilometers | Four years or 80,000 kilometers | Four years or 80,000 kilometers |
| body of automobile | |||
| Length (mm) | 4724 | 4720 | 4720 |
| Width (mm) | 1848 | 1848 | 1848 |
| Height (mm) | 1430 | 1442 | 1442 |
| Wheelbase (mm) | 2875 | 2875 | 2875 |
| Front wheelbase(mm) | 1582 | 1584 | 1584 |
| Rear wheelbase(mm) | 1560 | 1584 | 1584 |
| Weight (kg) | 1851 | 1760 | 1823 |
| Luggage compartment volume (L) | 594 | 594 | 594 |
| Number of doors (pcs) | 4 | 4 | 4 |
| Number of seats (pcs) | 5 | 5 | 5 |
| Sport Appearance Package | ● | - | - |
| electric motor | |||
| Total motor power (kW) | 343 | 194 | 331 |
| Total motor torque (N-m) | 723 | 340 | 559 |
| Maximum power of front electric motor (kW) | 137 | - | 137 |
| Maximum torque of front motor (N-m) | - | - | 219 |
| Maximum power of rear electric motor (kW) | 265 | 194 | 194 |
| Rear motor maximum torque (N-m) | - | 340 | 340 |
| CLTC pure electric range (km) | 623 | 606 | 713 |
| Battery capacity (kWh) | 78.4 | 60 | 78.4 |
| 100km power consumption (kWh/100km) | 14.4 | 11.3 | 12.5 |
| Motor structure | induction (elec.) | permanent magnetism | induction (elec.) |
| Principle of motor operation | synchronous | synchronization | synchronous |
| Second motor structure | permanent magnetism | - | permanent magnetism |
| Second motor working principle | synchronization | - | synchronization |
| Number of drive motors | Dual Motor | single motor | Dual Motor |
| Motor Layout | front and rear | place after (e.g. in grammar) | front and rear |
| Battery Type | Ternary lithium battery | lithium iron phosphate battery | Ternary lithium battery |
| Battery Cell Brands | Airola (Greek letter Εε) | Sichuan Times | Airola (Greek letter Εε) |
| Battery cooling method | liquid cooling | liquid cooling | liquid cooling |
| Battery Pack Warranty | Eight years or 192,000 kilometers | Eight years or 160,000 kilometers | Eight years or 192,000 kilometers |
| Battery preheating | ● | ● | ● |
| Chassis/steering | |||
| Driving form | four-wheel drive | rear drive | four-wheel drive |
| Front suspension type | double wishbone independent suspension | double wishbone independent suspension | double wishbone independent suspension |
| Rear suspension type | Multi-link independent suspension | Multi-link independent suspension | Multi-link independent suspension |
| Adjustable suspension | ● | - | - |
| Steering assist form | electric power assist | electric power assist | electric power assist |
| Wheels/Brakes | |||
| Front/Rear Brake Type | Ventilated tray type | Ventilated tray type | Ventilated tray type |
| Parking brake type | electronic parking | electronic parking | electronic parking |
| Front Tire Specification | 235/40 R19 | 235/45 R18 | 235/45 R18 |
| Rear Tire Specification | 265/35 R19 | 235/45 R18 | 235/45 R18 |
| Wheel Material | aluminum | aluminum | aluminum |
| Active/passive safety features | |||
| ABS anti-lock | ● | ● | ● |
| Brake force distribution (EBD/CBC etc.) | ● | ● | ● |
| Brake Assist (BA/EBA/BAS etc.) | ● | ● | ● |
| Traction control (ASR/TCS/TRC etc.) | ● | ● | ● |
| Stability Control (ESC/ESP/DSC etc.) | ● | ● | ● |
| Active braking/safety systems | ● | ● | ● |
| merging aid | ● | ● | ● |
| lane keeping assist system | ● | ● | ● |
| lane departure warning | ● | ● | ● |
| Road traffic signage recognition | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) |
| front exhaust airbag | :: Driver's airbag | :: Driver's airbag | :: Driver's airbag |
| ●Passenger airbag | ●Passenger airbag | ●Passenger airbag | |
| :: Intermediate airbags | :: Intermediate airbags | :: Intermediate airbags | |
| ●Side airbags | ●Side airbags | ●Side airbags | |
| ●Head airbags (air curtains) | ●Head airbags (air curtains) | ●Head airbags (air curtains) | |
| Rear airbags | ●Head airbags (air curtains) | ●Head airbags (air curtains) | ●Head airbags (air curtains) |
| Tire Pressure Detection Device | ●Display | ●Display | ●Display |
| Seat Belt Reminder | ● Full vehicle | ● Full vehicle | ● Full vehicle |
| ISOFIX child restraints | ● | ● | ● |
| Passive pedestrian protection | ● | ● | ● |
| Forward Collision Warning | ● | ● | ● |
| Sentinel mode/clairvoyance | ● | ● | ● |
| Auxiliary/Manipulation Configurations | |||
| Driver Assistance Video | ● Backup camera | ● Backup camera | ● Backup camera |
| cruise control | ●Adaptive cruise at all speeds | ●Adaptive cruise at all speeds | ●Adaptive cruise at all speeds |
| Driving Mode Switching | :: Campaigns | :: Economy | :: Campaigns |
| :: Economy | :: Standard/comfort | :: Economy | |
| :: Standard/comfort | :: Snow | :: Standard/comfort | |
| :: Snow | :: Snow | ||
| hill-holding aid | ● | ● | ● |
| automatic parking | ● | ● | ● |
| automatic parking | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) |
| remote control | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) | character used in Taiwan as a substitute for a real name (like "X" in English) |
| Assisted driving level | ●L2 | ●L2 | ●L2 |
| Driver Assistance System | ●Autopilot | ●Autopilot | ●Autopilot |
| External/anti-theft configurations | |||
| skylights | :: Segmented non-openable sunroof | :: Segmented non-openable sunroof | :: Segmented non-openable sunroof |
| Trunk opening method | ● Electric | ● Electric | ● Electric |
| Power trunk position memory | ● | ● | ● |
| Key Type | ○Remote key | ○Remote key | ○Remote key |
| ● Bluetooth key | ● Bluetooth key | ● Bluetooth key | |
| ●NFC/RFID key | ●NFC/RFID key | ●NFC/RFID key | |
| Keyless entry | ● | ● | ● |
| Keyless Start System | ● | ● | ● |
| Remote start function | ● | ● | ● |
| Central locking in the car | ● | ● | ● |
| Internal Configuration | |||
| Steering wheel material | ● Leather | ● Leather | ● Leather |
| Steering Wheel Adjustment | ● Electric | ● Electric | ● Electric |
| Adjustable up and down | Adjustable up and down | Adjustable up and down | |
| Adjustable front and rear | Adjustable front and rear | Adjustable front and rear | |
| Steering wheel functions | ●Heating | ●Heating | ●Heating |
| :: Memory | :: Memory | :: Memory | |
| :: Multifunctionality | :: Multifunctionality | :: Multifunctionality | |
| center armrest | ●Forward | ●Forward | ●Forward |
| ● Post | ● Post | ● Post | |
| Sun visor vanity mirror | ● | ● | ● |
| Built-in car recorder | ● | ● | ● |
| Wireless charging function for cell phones | ● Front row | ● Front row | ● Front row |
| Intelligent Hardware | |||
| Assisted Driving Chips | ●2 HW 4.0 | ●2 HW 4.0 | ●2 HW 4.0 |
| Number of cameras | :: 7 | :: 7 | :: 7 |
| seating | |||
| Seat Material | :: Imitation leather | :: Imitation leather | :: Imitation leather |
| sports seat | ● | - | - |
| Main Driver's Seat Function | :: Memory | :: Memory | :: Memory |
| :: Ventilation | :: Ventilation | :: Ventilation | |
| ●Heating | ●Heating | ●Heating | |
| Passenger seat function | :: Ventilation | :: Ventilation | :: Ventilation |
| ●Heating | ●Heating | ●Heating | |
| Seat electric adjustment | ●Principal Driver | ●Principal Driver | ●Principal Driver |
| ●Passenger | ●Passenger | ●Passenger | |
| Integral adjustment of the main driver's seat | ●Before and after | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | ●Backrests | |
| ●High/Low (4-way) | ●High/Low (4-way) | ●High/Low (4-way) | |
| Partial adjustment of the main driver's seat | :: Waist (4-way) | :: Waist (4-way) | :: Waist (4-way) |
| Passenger seat overall adjustment | ●Before and after | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | ●Backrests | |
| ●High/Low (4-way) | ●High/Low (4-way) | ●High/Low (4-way) | |
| Second row seat adjustment | ●Proportional lowering | ●Proportional lowering | ●Proportional lowering |
| Rear Cup Holder | ● | ● | ● |
| multimedia | |||
| Large color screen in the center console | ● | ● | ● |
| satellite navigation system | ● | ● | ● |
| Navigating the road information display | ● | ● | ● |
| In-vehicle Intelligent System | ● Tesla in-vehicle system software | ● Tesla in-vehicle system software | ● Tesla in-vehicle system software |
| Automotive Intelligence Chip | ●AMD Ryzen | ●AMD Ryzen | ●AMD Ryzen |
| Mobile APP Remote Function | ●Door control | ●Door control | ●Door control |
| ●Window control | ●Window control | ●Window control | |
| ● Vehicle start-up | ● Vehicle start-up | ● Vehicle start-up | |
| ● Charge management | ● Charge management | ● Charge management | |
| ● Air conditioning control | ● Air conditioning control | ● Air conditioning control | |
| :: Vehicle condition check/diagnosis | :: Vehicle condition check/diagnosis | :: Vehicle condition check/diagnosis | |
| :: Vehicle location/search | :: Vehicle location/search | :: Vehicle location/search | |
| ● Owner services (find charging stations, gas stations, parking lots, etc.) | ● Owner services (find charging stations, gas stations, parking lots, etc.) | ● Owner services (find charging stations, gas stations, parking lots, etc.) | |
| Bluetooth/Car Phone | ● | ● | ● |
| Number of audio speakers | 17 | 9 | 17 |
| Voice Recognition Control System | :: Multimedia systems | :: Multimedia systems | :: Multimedia systems |
| :: Navigation | :: Navigation | :: Navigation | |
| :: Telephone | :: Telephone | :: Telephone | |
| :: Air conditioning | :: Air conditioning | :: Air conditioning | |
| Center screen size | ●15.4 inches | ●15.4 inches | ●15.4 inches |
| 4G/5G networks | ●4G | ●4G | ●4G |
| Telematics | ● | ● | ● |
| OTA upgrade | ● | ● | ● |
| Rear LCD | ● | ● | ● |
| Rear LCD screen size | ●8 inches | ●8 inches | ●8 inches |
| Rear control multimedia | ● | ● | ● |
| Interface Support | ●Type-C port | ●Type-C port | ●Type-C port |
| illumination | |||
| low beam (headlights) | ●LED | ●LED | ●LED |
| high beam (headlights) | ●LED | ●LED | ●LED |
| LED daytime running lights | ● | ● | ● |
| Adaptive high and low beam | ● | ● | ● |
| Adjustable headlights | ● | ● | ● |
| Automatic headlights | ● | ● | ● |
| Delayed headlight off | ● | ● | ● |
| Interior ambient lighting | ● | ● | ● |
| Glass/Mirror | |||
| power window | ●Forward | ●Forward | ●Forward |
| ● Post | ● Post | ● Post | |
| One-touch window lifting | ● Full vehicle | ● Full vehicle | ● Full vehicle |
| Anti Window Pinch Handle | ● | ● | ● |
| rearview mirror | ●Motorized adjustment | ●Motorized adjustment | ●Motorized adjustment |
| :: Electric folding | :: Electric folding | :: Electric folding | |
| :: Memory | :: Memory | :: Memory | |
| ●Heating | ●Heating | ●Heating | |
| ●Automatic folding for locking the car | ●Automatic folding for locking the car | ●Automatic folding for locking the car | |
| ●Automatic reversing down | ●Automatic reversing down | ●Automatic reversing down | |
| rearview mirror | ●Automatic anti-glare | ●Automatic anti-glare | ●Automatic anti-glare |
| Glass Functions | :: Multi-layer soundproofing | :: Multi-layer soundproofing | :: Multi-layer soundproofing |
| inductive wiper | ● | ● | ● |
| Air conditioners/refrigerators | |||
| Air conditioning control method | ● Automatic control | ● Automatic control | ● Automatic control |
| rear air vent | ● | ● | ● |
| Temperature zone control | ● | ● | ● |
| PM2.5 filtration | ● | ● | ● |
