Exterior Design
The Kia KX1 is a subcompact SUV equipped with LED daytime running lights and LED taillight groups. The vehicle is fitted with 17-inch wheel rims. Partial versions are equipped with roof rails. The available exterior body colors include White, Black, Silver, Blue and Gray.
In terms of dimensions, the vehicle measures 4100 mm in length, 1735 mm in width, and 1533 mm in height, with a wheelbase of 2570 mm. It adopts a 5-door 5-seat layout. The rear seats support folding adjustment to expand rear cargo space.
Interior Design
The Kia KX1 is fitted with a central control touch screen. The interior is equipped with fabric seats as standard and leather seats for higher configurations, as well as a multi-function steering wheel. Partial versions support panoramic sunroof.
In terms of configurations, the standard model comes with front parking sensors, cruise control, front airbags, side airbags and automatic air conditioning. Higher-spec models are equipped with rearview camera and tire pressure monitoring system.
Powertrain
The Kia KX1 is equipped with a 1.4L naturally aspirated four-cylinder engine, paired with a 6-speed manual transmission or an IVT transmission. The engine delivers a maximum power of 73 kW and a peak torque of 132.4 Nm. All versions adopt a front-wheel drive layout.
The vehicle adopts front MacPherson independent suspension and rear torsion beam non-independent suspension. The vehicle has WLTC comprehensive fuel consumption of 5.8 L per 100 kilometers for manual transmission versions and 6.13 L per 100 kilometers for IVT versions. The maximum speed of the vehicle is 176 km/h.
| 2021 Kia KX1 1.4L Manual Fun Edition | 2021 Kia KX1 1.4L CVT Fun | 2021 Kia KX1 1.4L CVT Sunroof Model | |
|---|---|---|---|
| Basic Information | |||
| Availability | 2020.1 | 2021.01 | 2021.06 |
| vehicle class | compact SUV | compact SUV | compact SUV |
| Length*Width*Height(mm) | 4100*1735*1533 | 4100*1735*1533 | 4100*1735*1533 |
| Type of energy | gasoline | gasoline | gasoline |
| environmental standard | Country 6 | Country 6 | Country 6 |
| motor | 1.4L / 100 hp / Inline 4-cylinder | 1.4L / 100 hp / Inline 4-cylinder | 1.4L / 100 hp / Inline 4-cylinder |
| Maximum power (kW) | 73.6 | 73.6 | 73.6 |
| Maximum torque (N-m) | 132.4 | 132.4 | 132.4 |
| Number of gears | 6 | infinitely | infinitely |
| transmission | manual gearbox | CVT (Continuously Variable Transmission) | CVT (Continuously Variable Transmission) |
| Maximum speed (km/h) | 170 | 176 | 176 |
| NEDC Combined Fuel Consumption (L/100km) | 5.8 | 5.7 | 5.7 |
| WLTC Combined Fuel Consumption (L/100km) | 5.98 | 6.13 | 6.13 |
| Warranty Policy | Three years or 100,000 kilometers | Three years or 100,000 kilometers | Three years or 100,000 kilometers |
| body of automobile | |||
| Length (mm) | 4100 | 4100 | 4100 |
| Width (mm) | 1735 | 1735 | 1735 |
| Height (mm) | 1533 | 1533 | 1533 |
| Wheelbase (mm) | 2570 | 2570 | 2570 |
| Front wheelbase(mm) | 1516 | 1516 | 1516 |
| Rear wheelbase(mm) | 1526 | 1526 | 1526 |
| Weight (kg) | 1060 | 1104 | 1104 |
| Maximum full load mass (kg) | 1550 | 1600 | 1600 |
| Fuel tank volume (L) | 43 | 43 | 43 |
| Number of doors (pcs) | 5 | 5 | 5 |
| Number of seats (pcs) | 5 | 5 | 5 |
| Approach angle (°) | 18 | 18 | 18 |
| Departure angle (°) | 30 | 30 | 30 |
| motor | |||
| Displacement (mL) | 1368 | 1368 | 1368 |
| Engine Model | G4LC | G4LC | G4LC |
| Maximum horsepower (Ps) | 100 | 100 | 100 |
| Maximum power (kW) | 73.6 | 73.6 | 73.6 |
| Maximum net power (kW) | 73.6 | 73.6 | 73.6 |
| Maximum power speed(rpm) | 6300 | 6500 | 6500 |
| Maximum torque (N-m) | 132.4 | 132.4 | 132.4 |
| Maximum torque speed (rpm) | 4000 | 4000 | 4000 |
| cylinder (engine) | Inline 4-cylinder | Inline 4-cylinder | Inline 4-cylinder |
| engine position | preamplifier | preamplifier | preamplifier |
| Intake form | naturally aspirated | naturally aspirated | naturally aspirated |
| valve train | double overhead camshaft | double overhead camshaft | double overhead camshaft |
| Lubrication method | Multi-point electronic injection | Multi-point electronic injection | Multi-point electronic injection |
| Cylinder material | aluminum | aluminum | aluminum |
| fuel grade | 92# | 92# | 92# |
| environmental standard | Country 6 | Country 6 | Country 6 |
| Chassis/steering | |||
| Driving form | front drive | front drive | front drive |
| Front suspension type | MacPherson independent suspension | MacPherson independent suspension | MacPherson independent suspension |
| Rear suspension type | Torsion beam non-independent suspension | Torsion beam non-independent suspension | Torsion beam non-independent suspension |
| Steering assist form | electric power assist | electric power assist | electric power assist |
| Wheels/Brakes | |||
| Front/Rear Brake Type | Ventilated Disc Type / Disc Type | Ventilated Disc Type / Disc Type | Ventilated Disc Type / Disc Type |
| Parking brake type | handbrake | handbrake | handbrake |
| Front Tire Specification | 195/60 R16 | 195/60 R16 | 195/60 R16 |
| Rear Tire Specification | 195/60 R16 | 195/60 R16 | 195/60 R16 |
| Wheel Material | aluminum | aluminum | aluminum |
| Spare tire specification | Non-full size | Non-full size | Non-full size |
| Active/passive safety features | |||
| ABS anti-lock | ● | ● | ● |
| Brake force distribution (EBD/CBC etc.) | ● | ● | ● |
| Brake Assist (BA/EBA/BAS etc.) | ○ | ● | ● |
| Traction control (ASR/TCS/TRC etc.) | ○ | ● | ● |
| Stability Control (ESC/ESP/DSC etc.) | ○ | ● | ● |
| front exhaust airbag | :: Driver's airbag | :: Driver's airbag | :: Driver's airbag |
| ●Passenger airbag | ●Passenger airbag | ●Passenger airbag | |
| ●Side airbags | |||
| Tire Pressure Detection Device | ● Alarms | ● Alarms | ● Alarms |
| Seat Belt Reminder | ●Main driver's seat | ● Front row | ● Front row |
| ISOFIX child restraints | ● | ● | ● |
| Auxiliary/Manipulation Configurations | |||
| parking radar | ● Post | ● Post | ●Front |
| ● Post | |||
| Driver Assistance Video | ○Reverse Viewer | ● Backup camera | ● Backup camera |
| cruise control | - | - | ●Cruise control |
| steep incline and slow descent | - | ● | ● |
| hill-holding aid | ○ | ● | ● |
| External/anti-theft configurations | |||
| skylights | ○Power sunroof | - | ●Electric sunroof |
| roof rack | ● | ● | ● |
| Key Type | ●Remote key | ●Remote key | ●Remote key |
| Keyless entry | - | ● | ● |
| Keyless Start System | - | ● | ● |
| Central locking in the car | ● | ● | ● |
| electronic immobilizer | ● | ● | ● |
| Internal Configuration | |||
| Steering wheel material | :: Plastics | ● Leather | ● Leather |
| Steering Wheel Adjustment | ● Manual | ● Manual | ● Manual |
| Adjustable up and down | Adjustable up and down | Adjustable up and down | |
| Steering wheel functions | Multi-function | :: Multifunctionality | :: Multifunctionality |
| center armrest | ●Forward | ●Front | ●Forward |
| Gear Shift Form | ● Mechanical gearshift | ● Mechanical gearshift | ● Mechanical gearshift |
| Sun visor vanity mirror | ● | ● | ● |
| Intelligent Hardware | |||
| Number of cameras | ○1 | :: 1 | :: 1 |
| Number of ultrasonic radars | ● 3 | ● 3 | ● 5 |
| seating | |||
| Seat Material | :: Fabrics | :: Imitation leather | :: Imitation leather |
| Main seat adjustment | ●Forward and backward adjustment | ●Forward and backward adjustment | ●Forward and backward adjustment |
| Backrest adjustment | Backrest adjustment | Backrest adjustment | |
| ●High/low adjustment (2-way) | ●High/low adjustment (2-way) | ||
| Adjustment of passenger seat | ●Forward and backward adjustment | ●Forward and backward adjustment | ●Forward and backward adjustment |
| Backrest adjustment | Backrest adjustment | Backrest adjustment | |
| Second row seat adjustment | ●Proportional lowering | ●Proportional lowering | ●Proportional lowering |
| multimedia | |||
| Large color screen in the center console | ○Touch LCD | ●Touch LCD | ●Touch LCD |
| Bluetooth/car phone | ○ | ● | ● |
| Cell phone connectivity/mapping | ○Support CarPlay | ●CarPlay support | ●CarPlay support |
| ○CarLife support | ●CarLife support | ●CarLife support | |
| Number of audio speakers | 2 | 6 Horns | 6 |
| Center screen size | ○8 inches | ●8 inches | ●8 inches |
| Interface Support | ●USB port | ●USB port | ●USB port |
| Number of USB/Type-C ports | :: 1 in the front row | :: 1 in the front row | :: 1 in the front row |
| illumination | |||
| low beam (headlights) | ● Halogen | ● Halogen | ● Halogen |
| high beam (headlights) | ● Halogen | ● Halogen | ● Halogen |
| LED daytime running lights | - | ● | ● |
| Adjustable headlights | ● | ● | ● |
| Delayed headlight off | ● | ● | ● |
| front fog lights (of a motor vehicle) | ● | - | - |
| Glass/Mirror | |||
| power window | ●Front | ●Forward | ●Forward |
| ● Post | ● Post | ● Post | |
| outside rearview mirror | ●Motorized adjustment | ●Motorized adjustment | ●Motorized adjustment |
| ●Heating | |||
| rearview mirror | ●Manual anti-glare | ●Manual anti-glare | ●Manual anti-glare |
| rear wiper | ● | ● | ● |
| Air conditioners/refrigerators | |||
| Air conditioning control method | ●Manual control | ●Manual control | ● Automatic control |
