Exterior Design
The Cadillac OPTIQ is a compact luxury pure electric SUV, equipped with a closed front grille and full LED headlight groups. The vehicle is fitted with segmented LED taillight groups and aerodynamic rear bumper trim. Multiple body color options are available. The vehicle adopts 20-inch wheel configurations for different versions. Conventional door handles are equipped as standard. A panoramic sunroof is equipped as standard.
The vehicle adopts a 5-door 5-seater layout. The body dimensions are 4826 mm in length, 1977 mm in width and 1643 mm in height, with a wheelbase of 2946 mm. Electrically adjustable exterior mirrors and electric tailgate are standard configurations.
Interior Design
The vehicle is equipped with a 33-inch curved integrated screen combining full LCD digital instrument cluster and central control display. Multiple interior color schemes are available, matched with premium leather upholstery and metallic decorative trim. The vehicle supports multi-color ambient lighting and dual-zone automatic constant temperature air conditioning. An electronic gear shift lever is equipped as standard.
Standard configurations include front, side and curtain airbags, front and rear parking sensors, HD surround vision camera system and constant-speed cruise control. Keyless entry and one-key start functions are standard. High-spec versions are equipped with adaptive cruise control, lane keeping assist and active braking system. The vehicle supports wireless phone charging, 19-speaker AKG studio audio system and OTA upgrade functions.
Powertrain
The Cadillac OPTIQ adopts rear-wheel drive and dual-motor four-wheel drive layouts, matched with single-speed electric transmission. The rear-wheel drive version has a maximum motor power of 232 kW and a peak torque of 450 Nm. The four-wheel drive version has a system comprehensive maximum power of 324 kW and a peak torque of 675 Nm. The high-performance version has a system comprehensive maximum power of 380 kW and a peak torque of 880 Nm.
The vehicle is equipped with 85 kWh ternary lithium battery packs. The EPA comprehensive cruising range covers 302 miles for standard versions. The vehicle supports DC fast charging and AC slow charging functions. The vehicle is equipped with energy recovery system and adaptive damping suspension system.
| 2024 OPTIQ Standard Range Edition | 2024 OPTIQ 4WD Long Range Edition | |
|---|---|---|
| Basic Information | ||
| Availability | 2024.04 | 2024.04 |
| vehicle class | Medium SUV | Medium SUV |
| Length*Width*Height(mm) | 4822*1912*1644 | 4822*1912*1643 |
| Type of energy | all-electric | all-electric |
| CLTC pure electric range (km) | 536 | 600 |
| Total motor power (kW) | 180 | 211 |
| Total motor torque (N-m) | 330 | 465 |
| Maximum speed (km/h) | 180 | 180 |
| 0-100km/h acceleration(s) | 7 | 5.97 |
| Battery Type | Ternary lithium battery | Ternary lithium battery |
| Battery capacity (kWh) | 68.4 | 79.7 |
| Fast charging time (h) | 0.55 | 0.55 |
| Fast charging capacity (%) | 20-80 | 20-80 |
| Warranty Policy | Three years unlimited kilometers | Three years unlimited kilometers |
| body of automobile | ||
| Length (mm) | 4822 | 4822 |
| Width (mm) | 1912 | 1912 |
| Height (mm) | 1644 | 1643 |
| Wheelbase (mm) | 2954 | 2954 |
| Front wheelbase(mm) | 1622 | 1622 |
| Rear wheelbase(mm) | 1624 | 1624 |
| Weight (kg) | 2130 | 2300 |
| Luggage compartment volume (L) | 441-1362 | 441-1362 |
| Number of doors (pcs) | 5 | 5 |
| Number of seats (pcs) | 5 | 5 |
| Sport Appearance Package | - | ● |
| electric motor | ||
| Total motor power (kW) | 180 | 211 |
| Total motor torque (N-m) | 330 | 465 |
| Maximum power of front electric motor (kW) | 180 | 143 |
| Maximum torque of front motor (N-m) | 330 | - |
| Maximum power of rear electric motor (kW) | - | 68 |
| CLTC pure electric range (km) | 536 | 600 |
| Battery capacity (kWh) | 68.4 | 79.7 |
| 100km power consumption (kWh/100km) | 13.6 | 14.2 |
| Slow charging time (h) | 10.8 | 12.9 |
| Fast charging time (h) | 0.55 | 0.55 |
| Motor structure | permanent magnetism | permanent magnetism |
| Principle of motor operation | synchronization | synchronization |
| Second motor structure | - | induction (elec.) |
| Second motor working principle | - | synchronous |
| Number of drive motors | single motor | Dual Motor |
| Motor Layout | preamplifier | front and rear |
| Battery Type | Ternary lithium battery | Ternary lithium battery |
| Battery Cell Brands | Era SAIC | Era SAIC |
| Battery cooling method | liquid cooling | liquid cooling |
| fast charging function | be in favor of | be in favor of |
| Fast charging capacity (%) | 20-80 | 20-80 |
| Battery Pack Warranty | Eight years or 160,000 kilometers | Eight years or 160,000 kilometers |
| Battery preheating | ● | ● |
| Chassis/steering | ||
| Driving form | front drive | four-wheel drive |
| Front suspension type | MacPherson independent suspension | MacPherson independent suspension |
| Rear suspension type | Five-link independent suspension | Five-link independent suspension |
| Adjustable suspension | ● | ● |
| Steering assist form | electric power assist | electric power assist |
| Wheels/Brakes | ||
| Front/Rear Brake Type | Ventilated tray type | Ventilated tray type |
| Parking brake type | electronic parking | electronic parking |
| Front Tire Specification | 245/50 R20 | 245/50 R20 |
| Rear Tire Specification | 245/50 R20 | 245/50 R20 |
| Wheel Material | aluminum | aluminum |
| Spare tire specification | Tire Repair Tools | Tire Repair Tools |
| Active/passive safety features | ||
| ABS anti-lock | ● | ● |
| Brake force distribution (EBD/CBC etc.) | ● | ● |
| Brake Assist (BA/EBA/BAS etc.) | ● | ● |
| Traction control (ASR/TCS/TRC etc.) | ● | ● |
| Stability Control (ESC/ESP/DSC etc.) | ● | ● |
| Active braking/safety systems | ● | ● |
| merging aid | ● | ● |
| lane keeping assist system | ● | ● |
| lane departure warning | ● | ● |
| Automatic Lane Change Assist | - | ● |
| Road traffic signage recognition | ● | ● |
| Fatigue Driving Alerts | - | ● |
| DOW Open Door Alert | ● | ● |
| front exhaust airbag | :: Driver's airbag | :: Driver's airbag |
| ●Passenger airbag | ●Passenger airbag | |
| ●Side airbags | ●Side airbags | |
| ●Head airbags (air curtains) | ●Head airbags (air curtains) | |
| Rear airbags | ●Head airbags (air curtains) | ●Head airbags (air curtains) |
| Tire Pressure Detection Device | ●Display | ●Display |
| Seat Belt Reminder | ● Full vehicle | ● Full vehicle |
| ISOFIX child fixed seats | ● | ● |
| Forward Collision Warning | ● | ● |
| Rear Collision Warning | ● | ● |
| Auxiliary/Manipulation Configurations | ||
| parking radar | ●Forward | ●Forward |
| ● Post | ● Post | |
| Driver Assistance Video | ●360-degree panoramic image | ●360-degree panoramic image |
| cruise control | ●Adaptive cruise at all speeds | ●Adaptive cruise at all speeds |
| Driving Mode Switching | :: Campaigns | :: Campaigns |
| :: Standard/comfort | :: Standard/comfort | |
| :: Snow | :: Snow | |
| ● Customization/Personalization | ● Customization/Personalization | |
| hill-holding aid | ● | ● |
| automatic parking | ● | ● |
| automatic parking | ● | ● |
| Assisted driving level | ●L2 | ●L2 |
| Driver Assistance System | - | ●Super Cruise super assisted driving system |
| External/anti-theft configurations | ||
| skylights | ● Non-opening panoramic sunroof | ● Non-opening panoramic sunroof |
| Active Closed Grille | ● | ● |
| Concealed power door handles | ● | ● |
| Trunk opening method | ● Electric | ● Electric |
| ●Induction | ●Induction | |
| Power trunk position memory | ● | ● |
| Key Type | ●Remote key | ●Remote key |
| ● Bluetooth key | ● Bluetooth key | |
| Keyless entry | ● | ● |
| Keyless Start System | ● | ● |
| Remote start function | ● | ● |
| Central locking in the car | ● | ● |
| Internal Configuration | ||
| Steering wheel material | ● Leather | ● Leather |
| Steering Wheel Adjustment | ● Manual | ● Manual |
| Adjustable up and down | Adjustable up and down | |
| Adjustable front and rear | Adjustable front and rear | |
| Steering wheel functions | ●Heating | ●Heating |
| :: Multifunctionality | :: Multifunctionality | |
| center armrest | ●Forward | ●Forward |
| ● Post | ● Post | |
| Gear Shift Form | ●Electronic pocket shifter | ●Electronic pocket shifter |
| Sun visor vanity mirror | ● | ● |
| HUD Head-Up Display | - | ● |
| Built-in car recorder | ● | ● |
| active noise reduction | ● | ● |
| Wireless charging function for cell phones | ● Front row | ● Front row |
| Intelligent Hardware | ||
| Forward Sensing Camera | :: Monocular | :: Monocular |
| Number of cameras | ● 6 | ● 6 |
| Number of ultrasonic radars | :: 12 | :: 12 |
| Number of millimeter-wave radars | ● 5 | ● 5 |
| seating | ||
| Seat Material | :: Imitation leather | :: Imitation leather |
| Main Driver's Seat Function | :: Memory | :: Memory |
| :: Ventilation | :: Ventilation | |
| ●Heating | ●Heating | |
| Passenger seat function | :: Memory | :: Memory |
| :: Ventilation | :: Ventilation | |
| ●Heating | ●Heating | |
| Seat electric adjustment | ●Principal Driver | ●Principal Driver |
| ●Passenger | ●Passenger | |
| Integral adjustment of the main driver's seat | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | |
| ●High/Low (4-way) | ●High/Low (4-way) | |
| Partial adjustment of the main driver's seat | :: Waist (4-way) | :: Waist (4-way) |
| Passenger seat overall adjustment | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | |
| ●High/Low (4-way) | ●High/Low (4-way) | |
| Partial adjustment of the passenger seat | :: Waist (4-way) | :: Waist (4-way) |
| Second row seat adjustment | ●Proportional lowering | ●Proportional lowering |
| Rear Cup Holder | ● | ● |
| multimedia | ||
| Large color screen in the center console | ●Touch LCD | ●Touch LCD |
| satellite navigation system | ● | ● |
| Navigating the road information display | ● | ● |
| Roadside assistance calls | ● | ● |
| Automotive Intelligence Chip | Qualcomm Snapdragon 8195 | Qualcomm Snapdragon 8195 |
| Mobile APP Remote Function | ●Door control | ●Door control |
| ●Window control | ●Window control | |
| ● Vehicle start-up | ● Vehicle start-up | |
| ● Charge management | ● Charge management | |
| ● Air conditioning control | ● Air conditioning control | |
| :: Vehicle condition check/diagnosis | :: Vehicle condition check/diagnosis | |
| :: Vehicle location/search | :: Vehicle location/search | |
| Bluetooth/Car Phone | ● | ● |
| Cell phone connectivity/mapping | ●CarPlay support | ●CarPlay support |
| Audio Brand Name | AKG | AKG |
| Voice Recognition Control System | :: Multimedia systems | :: Multimedia systems |
| :: Navigation | :: Navigation | |
| :: Telephone | :: Telephone | |
| :: Air conditioning | :: Air conditioning | |
| Center screen size | ●33 inches | ●33 inches |
| Voice assistant wake words | Hello, Cadillac. | Hello, Cadillac. |
| 4G/5G networks | ●5G | ●5G |
| Telematics | ● | ● |
| OTA upgrade | ● | ● |
| Interface Support | ●Type-C port | ●Type-C port |
| Number of USB/Type-C ports | :: 4 in the front/2 in the back | :: 4 in the front/2 in the back |
| Power Support | 12V power supply for luggage compartment | 12V power supply for luggage compartment |
| illumination | ||
| low beam (headlights) | ●LED | ●LED |
| high beam (headlights) | ●LED | ●LED |
| LED daytime running lights | ● | ● |
| Adaptive high and low beam | ● | ● |
| Adjustable headlights | ● | ● |
| Automatic headlights | ● | ● |
| Delayed headlight off | ● | ● |
| Interior Ambient Lighting | ● | ● |
| Glass/Mirror | ||
| power window | ●Forward | ●Forward |
| ● Post | ● Post | |
| One-touch window lifting | ● Full vehicle | ● Full vehicle |
| Anti Window Pinch Handle | ● | ● |
| rearview mirror | ●Motorized adjustment | ●Motorized adjustment |
| :: Electric folding | :: Electric folding | |
| :: Memory | :: Memory | |
| ●Heating | ●Heating | |
| ●Automatic folding for locking the car | ●Automatic folding of locked car | |
| ●Automatic reversing down | ●Automatic reversing down | |
| rearview mirror | ●Automatic anti-glare | ●Automatic anti-glare |
| ●Streaming rearview mirror | ●Streaming rearview mirror | |
| Glass Functions | :: Multi-layer soundproofing | :: Multi-layer soundproofing |
| ● Rear side privacy | ● Rear side privacy | |
| Multi-layer acoustic glazing for side windows | ● Front row | ● Front row |
| inductive wiper | ● | ● |
| Air conditioners/refrigerators | ||
| Air conditioning control method | ● Automatic control | ● Automatic control |
| rear air vent | ● | ● |
| Temperature zone control | ● | ● |
| PM2.5 filtration | ● | ● |
