Exterior Design
The LIVAN 8 is a compact pure electric MPV, equipped with a closed front grille and full LED headlight groups. The vehicle is fitted with LED taillight groups and rear bumper trim. Multiple body color options are available. The vehicle adopts 17-inch wheel configurations for different versions. Conventional door handles are equipped as standard. Partial versions are equipped with roof rails.
The vehicle adopts 5-door 5-seater and 5-door 7-seater MPV layouts for different versions. The body dimensions are 4812 mm in length, 1909 mm in width and 1699 mm in height, with a wheelbase of 2807 mm. Electrically adjustable exterior mirrors with heating functions are equipped for different versions. An electric charging port cover is equipped as standard.
Interior Design
The vehicle is equipped with a full LCD digital instrument cluster and central control touchscreen. Multiple interior color schemes are available, matched with fabric and leather upholstery and metallic decorative trim. The vehicle supports automatic constant temperature air conditioning system. An electronic gear shift lever is equipped as standard.
Standard configurations include front and side airbags, front and rear parking sensors, rearview camera and constant-speed cruise control. Keyless entry and one-key start functions are standard. High-spec versions are equipped with 540-degree panoramic camera system, adaptive cruise control, lane keeping assist and active braking system. The vehicle supports vehicle network connection, V2L external discharge and OTA upgrade functions. Partial versions are equipped with multi-speaker audio system.
Powertrain
The LIVAN 8 adopts front-wheel drive layout, matched with single-speed fixed gear electric drive assembly. The vehicle is equipped with a front permanent magnet synchronous motor with maximum power of 100 kW and 120 kW for different versions, with a peak torque of 230 Nm and 240 Nm correspondingly.
The vehicle is equipped with 50.4kWh and 68.03kWh lithium iron phosphate battery packs for different versions. The CLTC pure electric cruising range covers 407 km and 515 km for different versions. The vehicle supports DC fast charging and AC slow charging functions. The vehicle is equipped with adjustable energy recovery system and multiple driving mode adjustment functions. The vehicle adopts front MacPherson independent suspension and rear torsion beam non-independent suspension system.
| 2025 Ray Blue 8 Standard Range Edition | 2025 Ray Blue 8 Long Range Edition | |
|---|---|---|
| Basic Information | ||
| Availability | 2024.11 | 2024.11 |
| vehicle class | Compact MPV | Compact MPV |
| Length*Width*Height(mm) | 4812*1909*1699 | 4812*1909*1699 |
| Type of energy | all-electric | all-electric |
| CLTC pure electric range (km) | 407 | 515 |
| Total motor power (kW) | 100 | 100 |
| Total motor torque (N-m) | 230 | 230 |
| Maximum speed (km/h) | 130 | 130 |
| Battery Type | lithium iron phosphate battery | Ternary lithium battery |
| Battery capacity (kWh) | 50.4 | 68.03 |
| Fast charging time (h) | 0.5 | 0.67 |
| Fast charging capacity (%) | 30-80 | 30-80 |
| Warranty Policy | Four years or 150,000 kilometers | Four years or 150,000 kilometers |
| body of automobile | ||
| Length (mm) | 4812 | 4812 |
| Width (mm) | 1909 | 1909 |
| Height (mm) | 1699 | 1699 |
| Wheelbase (mm) | 2807 | 2807 |
| Weight (kg) | 1805 | 1805 |
| Luggage compartment volume (L) | 459 | 459 |
| Number of doors (pcs) | 5 | 5 |
| Number of seats (pcs) | 7 | 7 |
| electric motor | ||
| Total motor power (kW) | 100 | 100 |
| Total motor torque (N-m) | 230 | 230 |
| Maximum power of front electric motor (kW) | 100 | 100 |
| Maximum torque of front motor (N-m) | 230 | 230 |
| CLTC pure electric range (km) | 407 | 515 |
| Battery capacity (kWh) | 50.4 | 68.03 |
| Fast charging time (h) | 0.5 | 0.67 |
| Motor structure | permanent magnetism | permanent magnetism |
| Principle of motor operation | synchronization | synchronization |
| Number of drive motors | single motor | single motor |
| Motor Layout | preamplifier | preamplifier |
| Battery Type | lithium iron phosphate battery | Ternary lithium battery |
| Battery cooling method | liquid cooling | liquid cooling |
| fast charging function | be in favor of | be in favor of |
| Fast charging capacity (%) | 30-80 | 30-80 |
| energy recovery | 1 | 1 |
| Battery Pack Warranty | Eight years or 200,000 kilometers | Eight years or 200,000 kilometers |
| Chassis/steering | ||
| Driving form | front drive | front drive |
| Front suspension type | MacPherson independent suspension | MacPherson independent suspension |
| Rear suspension type | Composite multi-link non-independent suspension | Composite multi-link non-independent suspension |
| Steering assist form | electric power assist | electric power assist |
| Wheels/Brakes | ||
| Front/Rear Brake Type | Ventilated Disc Type / Disc Type | Ventilated Disc Type / Disc Type |
| Parking brake type | electronic parking | electronic parking |
| Front Tire Specification | 215/60 R17 | 215/60 R17 |
| Rear Tire Specification | 215/60 R17 | 215/60 R17 |
| Wheel Material | Aluminum option | Aluminum option |
| Active/passive safety features | ||
| ABS anti-lock | ● | ● |
| Brake force distribution (EBD/CBC etc.) | ● | ● |
| Brake Assist (BA/EBA/BAS etc.) | ● | ● |
| Traction control (ASR/TCS/TRC etc.) | ● | ● |
| Stability Control (ESC/ESP/DSC etc.) | ● | ● |
| lane departure warning | - | ● |
| front exhaust airbag | :: Driver's airbag | :: Driver's airbag |
| ●Passenger airbag | ●Passenger airbag | |
| Tire Pressure Detection Device | - | ●Display |
| ISOFIX child restraints | ● | ● |
| Auxiliary/Manipulation Configurations | ||
| parking radar | ● Post | ● Post |
| Driver Assistance Video | ● Backup camera | ● Backup camera |
| cruise control | ●Cruise control | ●Cruise control |
| Driving Mode Switching | - | :: Economy |
| :: Standard/comfort | ||
| hill-holding aid | ● | ● |
| automatic parking | ● | ● |
| External/anti-theft configurations | ||
| Key Type | ●Remote key | ●Remote key |
| Keyless Start System | ● | ● |
| Central locking in the car | ● | ● |
| Internal Configuration | ||
| Steering wheel material | :: Plastics | :: Plastics |
| Steering Wheel Adjustment | ● Manual | ● Manual |
| Adjustable up and down | Adjustable up and down | |
| Adjustable front and rear | Adjustable front and rear | |
| Steering wheel functions | :: Multifunctionality | :: Multifunctionality |
| center armrest | ●Forward | ●Forward |
| ● Post | ● Post | |
| Gear Shift Form | ●Electronic gearshift | ●Electronic gearshift |
| Sun visor vanity mirror | - | ● |
| Liquid crystal instrument size | 7 inches. | 7 inches. |
| Intelligent Hardware | ||
| Number of cameras | :: 1 | :: 1 |
| Number of ultrasonic radars | ● 3 | ● 3 |
| seating | ||
| Seat Material | :: Imitation leather | :: Imitation leather |
| Integral adjustment of the main driver's seat | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | |
| ●High/Low (2-way) | ●High/Low (2-way) | |
| Passenger seat overall adjustment | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | |
| Second row seat adjustment | ●Angle adjustable | ●Angle adjustable |
| ● Seat movement | ● Seat movement | |
| ●Proportional lowering | ●Proportional lowering | |
| Second row of individual seats | ● | ● |
| Rear Cup Holder | ● | - |
| Third row of seats | ● | ● |
| Seat Layout | 2002/2/3 | 2002/2/3 |
| multimedia | ||
| Large color screen in the center console | ●Touch LCD | ●Touch LCD |
| Bluetooth/Car Phone | ● | ● |
| Number of audio speakers | 2 | 2 |
| Center screen size | ●10.33 inches | ●10.33 inches |
| Interface Support | ● USB port | ● USB port |
| Number of USB/Type-C ports | :: 1 front/3 rear | :: 1 front/3 rear |
| illumination | ||
| low beam (headlights) | ● Halogen | ● Halogen |
| high beam (headlights) | ● Halogen | ● Halogen |
| Adjustable headlights | ● | ● |
| Delayed headlight off | ● | ● |
| Glass/Mirror | ||
| power window | ●Forward | ●Forward |
| ● Post | ● Post | |
| One-touch window lifting | ● Full vehicle | ● Full vehicle |
| Anti Window Pinch Handle | ● | ● |
| rearview mirror | ●Motorized adjustment | ●Motorized adjustment |
| rearview mirror | ●Manual anti-glare | ●Manual anti-glare |
| Air conditioners/refrigerators | ||
| Air conditioning control method | ●Manual control | ●Manual control |
| rear air vent | ● | ● |
