Exterior Design
The Stelato S9 is a mid-to-large luxury sedan equipped with matrix LED headlight assemblies and through-type taillight groups. The vehicle is fitted with 19-inch and 20-inch wheel rims for different versions. The available exterior body colors include Starry Black, Cloud White, Nebula Gray, Streamer Blue, Aurora Purple, Streamer Silver and Wizard Green.
In terms of dimensions, the vehicle measures 5,160 mm in length, 2,005 mm in width, and 1,490 mm in height, with a wheelbase of 3,050 mm. It adopts a 4-door 5-seat layout. The vehicle is equipped with a front trunk storage space. The rear seats support folding adjustment to expand rear cargo space.
Interior Design
The Stelato S9 is fitted with a 12.3-inch full LCD digital instrument panel, a 16.1-inch floating central control touch screen and a 12.3-inch passenger entertainment screen. The vehicle is equipped with a 70-inch AR-HUD head-up display and a laser giant screen projection system. The interior color options include Obsidian Black, Cream White and dual-tone matching themes. The vehicle is equipped with Nappa leather seats and a multi-function steering wheel.
In terms of configurations, the standard model comes with front and rear parking sensors, rearview camera, cruise control, front and side airbags, and automatic air conditioning. Higher-spec models are equipped with Level 2 intelligent driving assistance system, 360-degree panoramic imaging system, active braking, 192-line or 896-line lidar sensing system and Huawei ADS 4.0 intelligent driving system. The vehicle is equipped with a 6.2L vehicle-mounted refrigerator and 25 speakers.
Powertrain
The Stelato S9 provides extended-range and pure electric powertrain versions. The extended-range model is equipped with a 1.5T turbocharged range extender and a rear single electric motor, paired with a single-speed electric transmission. The range extender delivers a maximum power of 118 kW. The electric motor delivers a maximum power of 227 kW and a peak torque of 320 Nm. The pure electric model offers rear-wheel drive and four-wheel drive layouts. The rear-wheel drive version has a maximum motor power of 227 kW. The four-wheel drive version adopts dual motors with a front motor power of 158 kW and a rear motor power of 227 kW, with a comprehensive maximum power of 385 kW.
The extended-range model is equipped with 37 kWh and 53.4 kWh battery packs, offering CLTC pure electric cruising ranges of 260 km and 372 km, with comprehensive cruising ranges of 1275 km and 1378 km. The pure electric model has CLTC cruising ranges of 721 km and 816 km for different versions. It supports fast charging and slow charging functions, with a 20%-80% fast charging duration of approximately 15 minutes.
| 2024 Stelato S9 Max Rear Drive Long Range | 2024 Stelato S9 Ultra 4WD Flagship | |
|---|---|---|
| Basic Information | ||
| vehicle class | Mid-size trim | Mid-size trim |
| Length*Width*Height(mm) | 5160*1987*1498 | 5160*1987*1486 |
| Type of energy | all-electric | all-electric |
| CLTC pure electric range (km) | 672 | 665 |
| Total motor power (kW) | 227 | 385 |
| Maximum speed (km/h) | 214 | 214 |
| Battery Type | Lithium Ternary + Lithium Iron Phosphate Battery | Ternary lithium battery |
| Battery capacity (kWh) | 79.9 | 97.6 |
| body of automobile | ||
| Length (mm) | 5160 | 5160 |
| Width (mm) | 1987 | 1987 |
| Height (mm) | 1498 | 1486 |
| Wheelbase (mm) | 3050 | 3050 |
| Front wheelbase(mm) | 1700 | 1706 |
| Rear wheelbase(mm) | 1730 | 1738 |
| Weight (kg) | 2216 | 2366 |
| Number of doors (pcs) | 4 | 4 |
| Number of seats (pcs) | 5 | 5 |
| electric motor | ||
| Total motor power (kW) | 227 | 385 |
| Maximum power of front electric motor (kW) | - | 158 |
| Maximum power of rear electric motor (kW) | 227 | 227 |
| CLTC pure electric range (km) | 672 | 665 |
| Battery capacity (kWh) | 79.9 | 97.6 |
| 100km power consumption (kWh/100km) | 13.1 | 16.1 |
| Motor structure | permanent magnetism | exchanges |
| Principle of motor operation | synchronization | synchronous |
| Second motor structure | - | permanent magnetism |
| Second motor working principle | - | synchronization |
| Number of drive motors | single motor | Dual Motor |
| Motor Layout | place after (e.g. in grammar) | front and rear |
| Battery Type | Lithium Ternary + Lithium Iron Phosphate Battery | Ternary lithium battery |
| Battery Cell Brands | Jiangsu Times | Jiangsu Times |
| Battery cooling method | liquid cooling | liquid cooling |
| Chassis/steering | ||
| Driving form | rear drive | four-wheel drive |
| Front suspension type | double wishbone independent suspension | double wishbone independent suspension |
| Rear suspension type | Multi-link independent suspension | Multi-link independent suspension |
| Adjustable suspension | ● | ● |
| air suspension | ● | ● |
| Steering assist form | electric power assist | electric power assist |
| Wheels/Brakes | ||
| Front/Rear Brake Type | Ventilated tray type | Ventilated tray type |
| Parking brake type | electronic parking | electronic parking |
| Front Tire Specification | 245/45 R20 | 245/40 R20 |
| Rear Tire Specification | 245/45 R20 | 245/45 R20 |
| Wheel Material | aluminum | aluminum |
| Active/passive safety features | ||
| ABS anti-lock | ● | ● |
| Brake force distribution (EBD/CBC etc.) | ● | ● |
| Brake Assist (BA/EBA/BAS etc.) | ● | ● |
| Traction control (ASR/TCS/TRC etc.) | ● | ● |
| Stability Control (ESC/ESP/DSC etc.) | ● | ● |
| Active braking/safety systems | ● | ● |
| merging aid | ● | ● |
| lane keeping assist system | ● | ● |
| lane departure warning | ● | ● |
| Road traffic signage recognition | ● | ● |
| Fatigue Driving Alerts | ● | ● |
| DOW Open Door Alert | ● | ● |
| front exhaust airbag | :: Driver's airbag | :: Driver's airbag |
| ●Passenger airbag | ●Passenger airbag | |
| :: Intermediate airbags | :: Intermediate airbags | |
| ●Side airbags | ●Side airbags | |
| ●Head airbags (air curtains) | ●Head airbags (air curtains) | |
| Rear airbags | ●Side airbags | ●Side airbags |
| ●Head airbags (air curtains) | ●Head airbags (air curtains) | |
| Tire Pressure Detection Device | ●Display | ●Display |
| Seat Belt Reminder | ● Full vehicle | ● Full vehicle |
| ISOFIX child restraints | ● | ● |
| Forward Collision Warning | ● | ● |
| Rear Collision Warning | ● | ● |
| Auxiliary/Manipulation Configurations | ||
| parking radar | ●Forward | ●Forward |
| ● Post | ● Post | |
| Driver Assistance Video | ●360-degree panoramic image | ●360-degree panoramic image |
| cruise control | ●Adaptive cruise at all speeds | ●Adaptive cruise at all speeds |
| Driving Mode Switching | :: Campaigns | :: Campaigns |
| :: Economy | :: Economy | |
| :: Standard/comfort | :: Standard/comfort | |
| ● Customization/Personalization | ● Customization/Personalization | |
| steep incline and slow descent | ● | ● |
| hill-holding aid | ● | ● |
| automatic parking | ● | ● |
| automatic parking | ● | ● |
| remote control | ● | ● |
| Assisted driving level | ●L2 | ●L2 |
| Driver Assistance System | ●HUAWEI ADS | ●HUAWEI ADS |
| External/anti-theft configurations | ||
| skylights | :: Segmented non-opening sunroof | :: Segmented non-opening sunroof |
| Concealed power door handles | ● | ● |
| Trunk opening method | ● Electric | ● Electric |
| Key Type | ● UWB digital key | ● UWB digital key |
| ●Remote key | ●Remote key | |
| ● Bluetooth key | ● Bluetooth key | |
| ●NFC/RFID key | ●NFC/RFID key | |
| Keyless entry | ● | ● |
| Keyless Start System | ● | ● |
| Remote start function | ● | ● |
| Central locking in the car | ● | ● |
| Internal Configuration | ||
| Steering wheel material | ● Leather | ● Leather |
| Steering Wheel Adjustment | ● Electric | ● Electric |
| Adjustable up and down | Adjustable up and down | |
| Adjustable front and rear | Adjustable front and rear | |
| Steering wheel functions | ●Heating | ●Heating |
| :: Memory | :: Memory | |
| :: Multifunctionality | :: Multifunctionality | |
| center armrest | ●Forward | ●Forward |
| ● Post | ● Post | |
| Sun visor vanity mirror | ● | ● |
| Built-in car recorder | ● | ● |
| Wireless charging function for cell phones | ● Front row | ● Front row |
| Intelligent Hardware | ● Rear | ● Rear |
| Number of ultrasonic radars | :: 12 | :: 12 |
| Number of millimeter-wave radars | ● 3 | ● 3 |
| Number of LiDAR | :: 1 | :: 1 |
| seating | ||
| Seat Material | ● Leather | ● Leather |
| Main Driver's Seat Function | :: Ventilation | :: Ventilation |
| :: Massage | :: Massage | |
| ●Heating | ●Heating | |
| Passenger seat function | :: Ventilation | :: Ventilation |
| :: Massage | :: Massage | |
| ●Heating | ●Heating | |
| Seat electric adjustment | ●Principal Driver | ●Principal Driver |
| ●Passenger | ●Passenger | |
| Integral adjustment of the main driver's seat | ●Before and after | ●Before and after |
| ●Backrests | ●Backrests | |
| ●High/Low (2-way) | ●High/Low (2-way) | |
| Partial adjustment of the main driver's seat | :: Waist (2-way) | :: Waist (2-way) |
| Second row seat adjustment | ●Angle adjustable | ●Angle adjustable |
| ● Seat movement | ● Seat movement | |
| ●Leg rest adjustment | ||
| Passenger seat rear adjustable buttons | ● | ● |
| Rear small table board | ● | ● |
| Rear Cup Holder | ● | ● |
| multimedia | ||
| Large color screen in the center console | ● | ● |
| satellite navigation system | ● | ● |
| Navigating the road information display | ● | ● |
| Map Branding | ●Gold | ●Gold |
| Roadside assistance calls | ● | ● |
| In-vehicle Intelligent System | ●HarmonyOS | ●HarmonyOS |
| Mobile APP Remote Function | ●Door control | ●Door control |
| ●Window control | ●Window control | |
| ● Vehicle start-up | ● Vehicle start-up | |
| ● Charge management | ● Charge management | |
| ● Air conditioning control | ● Air conditioning control | |
| :: Vehicle condition check/diagnosis | :: Vehicle condition check/diagnosis | |
| :: Vehicle location/search | :: Vehicle location/search | |
| ● Owner services (find charging stations, gas stations, parking lots, etc.) | ● Owner services (find charging stations, gas stations, parking lots, etc.) | |
| Bluetooth/Car Phone | ● | ● |
| Cell phone connectivity/mapping | ●HiCar support | ●HiCar support |
| Audio Brand Name | HUAWEI SOUND | HUAWEI SOUND |
| Number of audio speakers | 25 | 25 |
| Voice Recognition Control System | :: Multimedia systems | :: Multimedia systems |
| :: Navigation | :: Navigation | |
| :: Telephone | :: Telephone | |
| :: Air conditioning | :: Air conditioning | |
| ● Window | ● Window | |
| Voice assistant wake words | :: Xiaoyi Xiaoyi | :: Xiaoyi Xiaoyi |
| 4G/5G networks | ●4G | ●4G |
| facial recognition | ● | ● |
| Telematics | ● | ● |
| OTA upgrade | ● | ● |
| Multi-finger flying screen control | ● | ● |
| Rear LCD | ● | ● |
| Rear control multimedia | ● | ● |
| Interface Support | ● USB port | ● USB port |
| ●Type-C port | ●Type-C port | |
| Power Support | 12V power supply for luggage compartment | 12V power supply for luggage compartment |
| (stage) lighting | ||
| low beam (headlights) | ●LED | ●LED |
| high beam (headlights) | ●LED | ●LED |
| LED daytime running lights | ● | ● |
| Adaptive high and low beam | ● | ● |
| Adjustable headlights | ● | ● |
| Automatic headlights | ● | ● |
| Delayed headlight off | ● | ● |
| Interior Ambient Lighting | ● | ● |
| Glass/Mirror | ||
| power window | ●Forward | ●Forward |
| ● Post | ● Post | |
| One-touch window lifting | ● Full vehicle | ● Full vehicle |
| Anti Window Pinch Handle | ● | ● |
| rearview mirror | ●Motorized adjustment | ●Motorized adjustment |
| :: Electric folding | :: Electric folding | |
| ●Heating | ●Heating | |
| ●Automatic folding for locking the car | ●Automatic folding for locking the car | |
| rearview mirror | ●Automatic anti-glare | ●Automatic anti-glare |
| ●Streaming rearview mirror | ●Streaming rearview mirror | |
| Glass Functions | :: Multi-layer soundproofing | :: Multi-layer soundproofing |
| ● Rear side privacy | ● Rear side privacy | |
| sunshade | :: Rear windshield sunshade | :: Rear windshield sunshade |
| :: Rear side window sunshade | :: Rear side window sunshade | |
| inductive wiper | ● | ● |
| Air conditioners/refrigerators | ||
| Air conditioning control method | ● Automatic control | ● Automatic control |
| Individual air-conditioning in the rear | ● | ● |
| rear air vent | ● | ● |
| Temperature zone control | ● | ● |
| PM2.5 filtration | ● | ● |
| Negative Ion Generator | ● | ● |
| In-car scenting devices | ● | ● |
| Car Refrigerator | ● | ● |
